SIP T211P-ARC Transformer Welder
SKU
SIP05721
Need Some Help?
Low Prices!
Easy Returns
Easy Returns
The SIP T211P-ARC Transformer Welder has infinitely variable stepless output, giving superb versatility, plus an electrode-to-power gauge, which enables rapid setting of output current.
- 230v (20amp) / 400v (10amp) supply
- 60amp - 200amp (peak) output current
- 2.0mm - 4.0mm maximum electrode size
- 2.0mm - 8.0mm weld thickness (mild steel)
- Electrode-to-power gauge for rapid setting
- Infinitely variable step-less power output
- Wheel-mounted for practical movement
- Supplied with the following accessories:
- Wheel kit and chipping hammer
- 2 metre cable w/ electrode holder
- 2 metre Earth cable and clamp
- Handheld welding face shield
| Item No. | 05721 |
| Input Supply | 230v (20amp) 400v (10amp) |
| Output Current | 60amp - 180amp |
| Peak Current | 200amp |
| Duty Cycle | 180amp @ 10% |
| Electrode ∅ | 2.0mm - 4.0mm |
| Weld Thickness | 2.0mm - 8.0mm |
| Welding Voltage | 20.4v - 25.2v |
| Open Voltage | 50v |
| Power Factor | 0.6 |
| Efficiency | 46% |
| Insulation | Class F |
| Protection | IP21S |
| Gross Weight | 20.7kg |
| Packaged Dimensions | 325 x 285 x 515mm |
